Parylene Coating Machine JY-1000
| SKU | JY-1000 |
| Power Supply | 380V |
| Ambient Temperature | 0-40℃ |
| Ambient Humidity | <90% |
| Size | 5000*950*1500mm |
| SKU | JY-1000 |
| Power Supply | 380V |
| Ambient Temperature | 0-40℃ |
| Ambient Humidity | <90% |
| Size | 5000*950*1500mm |
Parylene vacuum coating technology can be widely used in aerospace, new energy vehicles, circuit boards, magnetic materials, sensors, silicone rubber, seals, medical devices, precious cultural relics and many other fields. The products coated by Parylene have extremely high insulation strength, high and low temperature resistance, acid and alkali corrosion resistance, lubrication, anti-adhesive, dustproof, waterproof, moisture-proof, rust-proof, transparent, anti-aging, biocompatible and other functions.
Automated design, capable of remote control
Uniform coating, good waterproof and pressure resistance performance
Short coating time and automated operation
| Working environment | |
| Power supply | 380V five wire |
| Power | 12KW |
| Temperature | 0-40 ℃ |
| Humidity |
<90% |
| Control system | |
| Visualization | Touch screen |
| System | PLC intelligent control system |
| Size | |
| Appearance size | 5000 * 950 * 1500mm |
| Floor area | 9 m²(including operational space) |
| Raw material tank | Φ 125 * 400mm |
| Capacity | 1000g |
| Deposition tank | Φ800 x L1000 |
| Working conditions | |
| Heating temperature | >200℃ |
| Temperature stability | <2℃ |
| Pyrolysis Heating temperature | <800℃ |
| Insulation Heating temperature | <300℃ |
| Rotating speed | Adjustable |
| Pumping speed | 30L/s |
| Cold trap | -90℃ |
Note: Other dimmension and performance can be customized
Aerospace
New energy vehicles
Medical equipment
Electronic components
